Installation
1.1
KHS Timer
The leak controller is intended for wall installa-
tion. The housing has 4 each ø 4 mm mounting
holes in a clearance of w = 148 mm and h = 50
mm.
To mount the cover, open the device and screw
tightly to the wall. After mounting the housing,
make the required electrical connections.
2
Electrical connection of the KHS Timer
2.1
Overview of the board | Terminal description
4 5
}
1
2
Connection power supply
3
}
4
Connection valve
5
6
1 2 6
3
© www.kemper-olpe.de – 11.2021 / K410068602012-00 – 25 / 32
1.2
KHS quarter turn stop valves
See separate installation and operating instruc-
tions, Figure 686 04 or Figure 686 05.
7 8
}
7
Connection Free Drain float switch over-
8
flow monitoring
Connections alarm relay
9
9
