Connecting Of The Khs Drain With Overflow Monitoring Figure 688 00 | 684; Using A Floating Alarm Relay, Terminal Pos - Kemper KHS Timer Einbau- Und Bedienungsanleitung

BN
BU
Connection KHS Drain with overflow monitoring
2.5
Figure 688 00 | 684 04
BN
WS
Using a floating alarm relay,
2.6
terminal item 9
e.g. indicator light
e.g. alarm horn
Extrenal voltage
max. 230 V, 2 A
BN = brown
WS = white
BN = brown
WS = white
N
N
e.g. Input BMS or alarm system
© www.kemper-olpe.de – 11.2021 / K410068602012-00 – 27/ 32
Connection of valve V1
Terminal item 4 and 6
Terminal item 7 and 8
The controller is preset for connecting the KHS
Free drain. The bridge on Terminal IN3 must be
removed.
Terminal item 9
The controller is preset for connecting the KHS
Free drain. The bridge on Terminal IN3 must be
removed.
Example: Closing relay version
