3

Operating | Menu guidance

3.1

Menu guidance

The KHS Timer can be operated with the buttons
via the displayed menu in the display.Use the
arrow button - up / down to select the menu
items. The selection is confirmed with OK. In the
submenus the button Manual is used as the
"ESC" key.
Performance test |
3.2
Manual function of the valve
To make sure that the valve is functioning, it is
recommended to run a performance test.
To do that, press the Manual button once. Then
the valve opens or closes manually.
3.3

Initial setting during commissioning

During initial commissioning the basic settings
language, date and time are to be made.
28 / 32 – K410068602012-00 / 11.2021 – © www.kemper-olpe.de
From softwareversion V1.03: version with display
lighting.
- The first press turns on only the backlight of the
display.
- If an error occurs, the display turns on automati
cally.
After about 3.5 minutes, the display light shutts
off and the control returns to the main display.
Pressing the button Manual again puts the KHS
Timer back into automatic mode.
Manual mode remains active until the next timer
switching point and then returns to automatic
mode.
(Initial setting after starting the menu for the first
time)
1. Press arrow button
2. Query: Confirm „Make initial settings" with OK
3. Enter parameters: Language, Time, Date
4. The display indicates > Operation <
