DMX

DMX CONTROL / DMX STEUERUNG / PILOTAGE DMX / CONTROL DMX /
STEROWANIE DMX / CONTROLLO DMX
(preselect color in stand-alone mode Static, CCT, Color Preset or User Color)
Ch. Function
1 Dimmer
Ch. Function
1 Dimmer
2 Strobe functions
1CH Mode
Values
000 - 255 0% to 100%
3CH1 Mode
Values
000 - 255 0% to 100%
000 - 005 Strobe open
006 - 010 Strobe closed
011 - 022 Ramp up/down, slow -> fast
Ramp up/down random,
023 - 033
slow->fast
034 - 045 Ramp up, slow -> fast
Ramp up random, slow ->
046 - 056
fast
057 - 068 Ramp down, slow -> fast
Ramp down random, slow
069 - 079
-> fast
Random Strobe effect, slow
080 - 102
-> fast
Strobe Break effect, 5s.....1s
103 - 127
(short burst with break)
Strobe slow -> fast <1Hz -
128 - 250
20Hz
251 - 255 Strobe open
Sub-Group
Dimmer
Sub-Group
Dimmer
Multifunctional
Strobe
