M-Series
If you have a CNC router from a different brand, check the external documentation to connect the laser
to the data output of the specific CNC router. If you are using third-party products, such as another CNC
NOTICE
router mainboard, you are solely responsible for connecting the emergency stop functionality properly to the
DL445 controller.
Never bridge the safety system manually on purpose. Use of the laser tool for operations different from those
intended could result in a hazardous situation with high probability of superficial injury.
Attach the laser head to the 43 mm euro tensioning system of
the STEPCRAFT machine or the adequate CNC router. Be aware
of the mounting position safety switch. Only when the laser
head is mounted correctly, the safety switch is pressed down.
53
D-Sub 15
