4. INSTALLATION METHOD
5. Fasten the back plate of the smart port
For exposed mounting, fasten the back plate on the wall
with the 3 screws (M4×20) and plugs. (Fig.4-5)
6. .Insert the smart kit with slightly strength into the main PCB
of the smart port .(Fig.4-6)
Back plate
Screws (M4×20)
Fig 4-6
Fig 4-5
