1. Pull the braking lever up to release the brakes. Pictured in released position.
2. Push the braking lever down to lock the nursing bed. Pictured in locked position.

5.6 Moving and braking (sentida 7-i mobile)

To activate the brake bar, move the bed into the bed egress position or higher. The brake bar
can now be activated with the foot in three positions.
Position 01: Brake
Position 02: Can be moved
Position 03: Direction locking
(The tilting movement of the left castor at the
head end is blocked, thereby making it easier to
maneuver the bed.)
When moving the bed, please adhere to the following steps:
▪
Release the brakes.
▪
At its head or foot end, move the bed to the desired position.
▪
Then, activate the brakes again by pushing the brake bar .
74
2
03
02
01
