5.4 USING MOP ADAPTER (FIG. 3)
Using the vacuum cleaner with the mop adapter requires installation of the water tank B.
1) Fill clean water into the tank through opening B4 and close with plug B5.
2) Install the tank into the vacuum cleaner.
3) Then install the mop adapter C with attached mop (a click will be heard) on the bottom
side of the device. Soak and wring the mop before use.
4) Switch on the vacuum cleaner by pressing button A6 or using the app.
– Do not forget to slide the short and straight part of the mop onto adapter C and put
its remaining part on the velcro (part C2).
– The pumping function will be activated by inserting the mop adapter C. Don´t use the
vacuum cleaner with adapter C without water in the tank of adapter B!
– Monitor the device during cleaning operation. Constantly monitor mopping operation.
– When mopping, we recommend cleaning the individual rooms.
– When mopping, check the vacuum cleaner and add water, if necessary, or rinse the
mop.
– Do not use the mop attachment on carpets and prevent the vacuum cleaner from
hitting the carpet (alternatively, you can use prohibited zone function in the app
which can be set for floors with carpets).
– Remove and clean the moping attachment after use. Do not leave it installed on the
vacuum cleaner while charging.
– After closing the tank with the plug, small water volume can leak through bottom
holes. After filling and closing, turn the water tank upside down and carry in this
position.

6. VACUUM CLEANER MAINTENANCE

Carry out maintenance and cleaning regularly, depending on the frequency of use and
the amount of cleaning. In a more polluted environment (a pet household), more frequent
maintenance will be required. Failure to carry out maintenance may damage the
vacuum cleaner and its components!
6.1 CHARGING CONTACTS CLEANING
Switch off the vacuum cleaner and disconnect the charging station from the power
supply! Clean the charging contacts (A3, D3) on the vacuum cleaner and on the station
with a soft dry cloth. Clean at least once a month. Do not use aggressive cleaning
agents or oils to clean the contacts.
Carefully wipe vacuum cleaner body incl. laser module with dry cloth. Remove dirt (if any)
in the laser module area (the dirt could deactivate the rotation mechanism and result in
deterioration of the surface mapping function and behaviour of the device.)
When turning the device, don´t put it on the laser module. Risk of damage!
