How to Use Basic Functions

Basic operation
ATTENTION! Before operation, please
ensure the unit is plugged in and power
is available.
1
1
3
3
2
2
Swing
Boost Clean
COOL Mode
1. Press the MODE button to select COOL
mode.
2. Set your desired temperature using the
TEMP or TEMP button.
3. Press FAN button to select the fan speed
in a range of AU-100%.
Press the ON/OFF button to start the unit.
4.
SETTING TEMPERATURE
The operating temperature range for units
is 16-30°C (60-86°F)/20-28 C(68-82 F).
You can increase or decrease the set
temperature in 1°C (1°F) increments.
AUTO Mode
In AUTO mode, the unit will automatically select
the COOL, FAN, HEAT or DRY function based on
the set temperature.
1. Press the MODE button to select AUTO.
2. Set your desired temperature using the TEMP
or TEMP button.
3. Press the ON/OFF button to start the unit.
NOTE: FAN SPEED can't be set in AUTO mode.
1
1
4
4
2
2
3
3
Swing
Boost
Clean
58
1
1
3
3
2
2
Swing
Boost
Clean
FAN Mode
Press the MODE button to select FAN mode.
1.
2. Press FAN button to select the fan speed
in a range of AU-100%.
Press the ON/OFF button to start the unit.
3.
NOTE: You can't set temperature in FAN mode.
As a result, your remote control's LCD screen
will not display temperature.
1
1
4
4
2
2
3
3
B o o s t
DRY Mode (dehumidifying)
1. Press the MODE button to select AUTO.
2. Set your desired temperature using the TEMP
or TEMP
button.
3. Press the ON/OFF button to start the unit.
NOTE: FAN SPEED cannot be changed in DRY
mode.
1
1
3
3
2
2
Boost Clean
HEAT Mode
1. Press the MODE button to select HEAT
mode.
2. Set your desired temperature using the
TEMP or TEMP button.
3. Press FAN button to select the fan speed
in a range of AU-100%.
Press the ON/OFF button to start the unit.
4.
NOTE: As outdoor temperature drops, the
performance of your unit's HEAT function may
be affected. In such instances, we recommend
using this air conditioner in conjunction with
other heating appliances.
59
