POLARITY
Menu item for setting the polarity of channels A to D. Press the MENUdial to access the device settings menu and then turn it to select the menu
item POLARITY (light background). Now press the dial and then turn it to select the channel that you want to configure (channel A - D). Press the
dial again, select the required polarity and confirm by pressing the dial (NORMAL = normal polarity, INVERTED = inverted polarity). Repeat this proce-
dure to select the polarity for the other channels. To return to the selection menu, turn the dial to select the menu item POLARITY EXIT and confirm
by pressing the dial. Access the main display by turning the dial to select EXIT (light background) and confirm by pressing the dial. Following
approximately 10 seconds of no input, the main display will appear automatically.
LINK SETT
Channels A to D can be linked as required in order to have parallel settings for volume, delay and EQ on the selected channels. This means that the
settings on one of the linked channels will be transferred simultaneously to the other linked channels. Settings that have been configured prior to
linking will be retained until the value of the corresponding parameter is changed. This means that if settings are changed for one channel, they will
be transferred to the linked channel. Press the MENUdial to access the device settings selection menu, then turn the dial to select the menu item LINK
SETT(bright background). Now press the dial and then turn it to select the channel that you want to link with other channels. Press the dial again and
then turn it to select the desired link (UNLINK to deactivate a link). Confirm your selection by pressing the dial. A link is indicated by a "connection bar"
between the corresponding letters shown in the display. To return to the main display, turn the dial to select the menu item LINK EXIT and confirm by
pressing the dial. To return to the main display, turn the dial to select the menu item EXIT (light background) and confirm by pressing the dial. Following
approximately 10 seconds of no input, the main display will appear automatically.
PRESET
Menu item for selecting loudspeaker presets for speakers from the LD CURV series. For example, select the preset 6 CURV-SATon the Smart Link®
adapter for the appropriate channel if you wish to connect 6 x CURV 500 array satellites; select the preset 1 CURV SUB if you want to connect the
CURV 500 installation-subwoofer (note: select the preset that corresponds with the number of satellites per SmartLink
adapter). Press the rotary
®
MENUdial to access the device settings selection menu and then turn the dial to select the menu item PRESET (bright background). Now press the
dial and then turn it to select the desired channel for the preset. Press the dial again and then turn it to select the desired preset. Confirm your
selection by pressing the dial. Repeat this procedure to configure presets for the other channels. To return to the main display, turn the dial to
select the menu item PRESET EXIT and confirm by pressing the dial. To return to the main display, turn the dial to select the menu item EXIT (light
background) and confirm by pressing the dial. Folloing approximately 10 seconds of no input, the main display will appear automatically.
