10.3.1 Releasing excess pressure
Release the excess pressure by switching off the
compressor and using the compressed air which
is still left in the pressure vessel, e.g. with a com-
pressed air tool running in idle mode or with a blow-
out pistol.
10.4 Transport (fig. 2/4)
The compressor can be transported with the handle
(16). To do so, wind the mains cable (14) onto the
cable holder (4).

11. Disposal and recycling

The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material
and can therefore be reused or can be returned to
the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic. De-
fective components must be disposed of as special
waste. Ask your dealer or your local council.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must
not be disposed of together with domestic
waste in compliance with the Directive
(2012/19/EU) pertaining to waste electrical
and electronic equipment (WEEE). This product must
be disposed of at a designated collection point.

13. Troubleshooting

Fault
The compressor does
not start.
The compressor starts
but there is no pres-
sure.
The compressor
starts, pressure is
shown on the pressure
gauge, but the tools
do not start.
Heruntergeladen von manualslib.de

Possible cause

• No supply voltage.
• Insufficient supply voltage.
• Outside temperature is too low.
• Motor is overheated.
• The non-return valve leaks.
• The seals are damaged.
• The drain plug for condensation water (1)
leaks.
• The hose connections have a leak.
• A quick-lock coupling has a leak.
• Insufficient pressure set on the pressure
regulator (7).
Handbücher-Suchmachiene
This can occur, for example, by handing it in at an
authorised collecting point for the recycling of waste
electrical and electronic equipment. Improper han-
dling of waste equipment may have negative conse-
quences for the environment and human health due
to potentially hazardous substances that are often
contained in electrical and electronic equipment.
By properly disposing of this product, you are also
contributing to the effective use of natural resources.
You can obtain information on collection points for
waste equipment from your municipal administration,
public waste disposal authority, an authorised body
for the disposal of waste electrical and electronic
equipment or your waste disposal company.

12. Spare-part ordering

Please quote the following in your order for spare
parts:
• Type of device
• Article No. of deviceIdent. No. of device
• Spare Part No. of the required spare part
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the
following parts are therefore also required for use
as consumables.
Wear parts*: Cylinder, piston, piston rings
* Not necessarily included in the scope of delivery!
Remedy
• Check the supply voltage, the power plug and
the socket-outlet.
• Make sure that the extension cable is not
too long. Use an extension cable with large
enough wires.
• Never operate with an outside temperature of
below +5° C.
• Allow the motor to cool down. If necessary,
remedy the cause of the overheating.
• Have a service center replace the non-return
valve.
• Check the seals and have any damaged seals
replaced by a service center.
• Tighten the screw by hand. Check the seal on
the screw and replace if necessary.
• Check the compressed air hose and tools and
replace if necessary.
• Check the quick-lock coupling and replace if
necessary.
• Increase the set pressure with the pressure
regulator.
GB 77
