Endress+Hauser Proline Promag 800 Index C Installationsanleitung Seite 9

5 →
2.
1.
‣
Disconnect the terminals.
7 →
B
‣
Disconnect the plug for the pressure sensor.  This step must only be
performed if a pressure sensor is present.
8 →
‣
Disconnect the plug of the electronics module.
Endress+Hauser
6 →
A
3.
‣
Disconnect the plug for the external battery.  This step must only be
performed if an external battery is present.
A
9 →
‣
Loosen the Torx screws of the
electronics module.
EA01325D
B
1 Nm
(0.7 lbf ft)
T10
9
