2. Device powered by battery: set switch B to "OFF" position (switch is located on the main
electronics module), see graphic below.
1
A B
7.2 Replacing the O-ring for sensor connector, profile seal for sensor
1 →
T20
2.
‣
Loosen the Torx screws, open the
cover.
3 →
‣
Push the display module down gently at the hinge and push out of the
holder.
8
2 →
1.
2.
‣
Open the display module, push the ribbon cable out of the holder,
disconnect the plug.
2.
1.
1.
4 →
‣
Remove the display module.
