When External CAN operating mode is active, you can set the Baud rate
for the CAN bus and connect up to 5 external sensors (max. 5 channels).
Select a message type for each channel. The following signal types are
available:
■ CANopen PDO
■ CAN Generic
Define the parameters for the selected channel according to your
application.
Fig. 46 CAN-Y connection port, settings
For further information, refer to the & Technical Data related to the
sensors connected.
INFORMATION
When External CAN operating mode is active, the settings may only
be defined by properly trained technicians.
