Technical Data

11. Technical Data
This chapter contains information on the technical data of the device and
input modules available.
11.1 Device Model
Device Connections
HPM7000-BS 2 CAN bus
1 D-IN
1 D-OUT
2 frequencies
11.2

Mechanical Data

Designation
Dimensions
Weight
Type of protection
Ambient temperature
Storage temperature
Relative humidity
Housing
Protective casing
VESA holder
Fold-out stand
Slot
11.3 Touchscreen Data
Designation
Type
Resolution
Size
Surface
Back-lit display
Brightness
Reading angle
126
Sensors Channels
24 CAN X 24
24 CAN Y 24
1 D-IN 1
1 D-OUT 1
2 2
Property
282 × 195 × 85 mm
1.880 g
IP65 (EN/IEC 60529:2014), all screw-in connections must
be fitted with sensors or protective caps
-10 – +50 °C
-20 – +60 °C
0 – 80 %
ABS/PC, thermoplastic
TPE, thermoplastic elastomer
100 mm × 100 mm / M4 metric
40° angle of inclination
2× for input module
Property
P Cap multi-touchscreen, antireflective
800 × 480 pixels
7"
3 mm glass (scratchproof)
0 – 100% adjustable
450 cd
90° from all angles
Scanning rate
>1 ms
>1 ms
1 ms
1 ms
1 ms
