Operation
In order to analyze measurements which have been saved, various
functions are available using the options provided after pressing the
Curve tools button:
1 Open one of the measurements previously saved. Further
information is available in Chapter & "File Manager".
Fig. 28 Curve tools
2 Tap on the
Ä The options are displayed.
3 Tap on the Curve tools button.
Ä The functions available are displayed:
Designation
Jump to MIN
Jump to MAX
Cursor ON/OFF
X/Y axis
4 Tap on the appropriate button.
Ä The function selected is performed.
60
button.
Description
The cursor springs to the minimum value of the
selected channel
The cursor springs to the maximum value of the
selected channel
Unhide or hide the cursor
Adjust the scaling of the axes
