6.4 Measurement Status
A measurement is started and stopped using the Start/Stop button or
the blue function key on the device.
The Start/Stop button indicates the current status of a measurement.
The following statuses can be configured:
Status Description
Measurement has not yet been started, adjustments can
be made.
Measurement is activated, the device is waiting for the
defined trigger to be triggered in order to record the mea-
sured data.
Measurement is started and measured data is recorded.
1 Tap on the Start/Stop button.
Ä The measurement starts up.
INFORMATION
Alternatively, press the blue function key on the device.
Recording of the measured data begins according to the measuring
method selected, either immediately or after triggering one or several
triggers.
The current runtime of the measurement is displayed underneath the
Start/Stop button.
2 Tap on the Start/Stop button.
Ä The measurement is stopped.
