General safety notes
2.1 Intended use
The machine is intended for the stripping and crimping
of flexible wires in one work process. Only the material
described below (wires and wire-end ferrules) may be
processed using the machine. Process-safe processing
can only be guaranteed for Weidmüller wire-end ferrules.
The processing of other makes may lead to faults and
damage to the machine.
The machine must only be used within the technical limits
described (see section 3.1). Modifications to and recon-
structions of the machine must not be performed.
Intended use also includes paying attention to the docu-
mentation.
2.2 Material that can be processed and crim-
ping shape
Wires
Flexible PVC cable H05V-K and H07V-K with a cross sec-
tion of 0.5–2.5 mm².
Wire-end ferrules
Weidmüller belted wire-end ferrules:
H0,5/14
H0,5/14 S
H0,75/14
H0,75/14 S
H1,0/14
H1,0/14 S
H1,5/14
H1,5/14 S
H2,5/14
H2,5/14 S
H0,5/14
H0,5/14 S
H0,75/14
H0,75/14 S
H1,0/14
H1,0/14 S
H1,5/14
H1,5/14 S
H2,5/14
H2,5/14 S
Crimp form
Trapezium (standard)
2549630000/00/09.2017
Model R
Model RS
H0,5/16
H0,5/16 S
H0,75/16
H0,75/16 S
H1,0/16
H1,0/16 S
H1,5/16
H1,5/16 S
H2,5/16
H2,5/16 S
2.3 Safety equipment
The machine is equipped with the following safety devices:
– Safety switch inside on the front plate
– 3/2-distributing valve
– Mains adapter
These items of safety equipment must not be rendered
ineffective. They must be checked once per year by a ser-
vice technician.
2.4 Personnel
Only trained personnel may operate the machine and per-
form maintenance activities. Training also includes having
fully read the operating instructions.
Repairs may only be performed following con-
sultation with Weidmüller Service and only by
an electrical specialist.
Keep the operating instructions stored so that
they can be inspected by operating personnel
at any time.
All documents can also be downloaded from
the Weidmüller website.
