4. Symbols Description

Conforms to the relevant European Union directive (EN-61010)
Product is protected by double insulation
Risk of Danger. Important information See instruction manual
Hazardous voltage!
This product should not be disposed along with normal
domestic waste at the end of its service life but should be
handed over at a collection point for recycling electrical and
electronic devices.
The device is designed for making measurements in building
installations. Examples are measurements on junction boards,
CAT III circuit breakers, wiring, switches, permanently installed
sockets, devices for industrial use as well as permanently
installed motors.
600 V max. voltage to earth (AC / DC)
FUSED Fused current measuring range
DC voltage / current (DC)
AC voltage (AC)
Fuse(s)
Battery compartment / Battery test
Ground / Earth (max. voltage to earth)
