Programming
Planning Schedule
Enable
View/Edit
Sched. sequence
Reset
Restart
Delay
Min. autonomy
Shutdown
Delay
Tools
Segnalling Test
LCD Display Test
Battery Test
Battery Calibration
All manuals and user guides at all-guides.com
Enable
To enable or disable set programmes
➧
View/Edit
To set and modify programmes. The following functions are
available:
- Batteries Test (verifies the status of the batteries)
- Batt. Calibration (calibration of the batteries)
- Turn on (to switch the UPS on)
- Turn off (to switch the UPS off)
- Absent (disables programming)
Each programme can be executed in the following ways:
- Daily "hour-minutes": executed every day at the set hour-
minutes;
- Single "day –month –hour -minutes": executed once on
the set "day –month –hour -minutes"
- Weekly "day name –hour -minutes" : executed every week
on the set "day name –hour -minutes".
Sched.
Used to display all the set programmes in the daily order
sequence
(max 16)
Reset
Deletes all settings
➧
Duration, in seconds, of the warning signal that the UPS is
Delay
about to switch back on
Min.
Percentage of battery charge below which the UPS will not
Autonomy
automatically switch back on
➧
Duration, in seconds, of the warning signal that the UPS is
Delay
about to switch back on
Signalling
Tests the warning lights. Press the ENTER button to
Test
execute the test of the Green, Yellow and Red warning
➧
lights and the Acoustic warning signal.
LCD
Tests the alphanumeric display. Press the ENTER button
and all the available digits are shown on the alphanumeric
Display Test
display.
Tests the batteries. Contact your Service Centre in case of
Battery Test
problems.
Battery
Calibrates the batteries, calculating the discharge curve for
the batteries. We recommend this cycle be carried out
Calibration
when the batteries have been changed so that the UPS is
able to provide precise information regarding the status of
their charge.
4 - Customising the UPS operating mode
