Set The Language; Events - Meta System Megaline 1250 Rack Bedienungsanleitung

4 - Customising the UPS operating mode
Batteries
Max Time On Batt.
Max time reserve
TurnOn Test Enable
Restart Enable
External options
Setup Clock
23/06/03 -19:25:06
Monday
Operator Panel
Language
Keyboard Beep
Display Backlight
Display contrast
Password Change

Events

Log View
Log Reset
All manuals and user guides at all-guides.com
Max Time On
Sets the maximum time for continuous operation in
Batt.
BATTERY mode, shown in seconds. If "0" is set, this
➧
function is disabled.
Max time Sets the maximum time for operation in BATTERY mode
after the reserve limit has been reached, shown in seconds.
reserve
If "0" is set, this function is disabled.
If enabled, the batteries are tested each time the UPS is
TurnOn Test
switched on. If disabled, the batteries are not tested when
Enable
it is switched on again.
Restart Enable
If enabled, the UPS will switch on again when mains power
is restored after switching off due to the end of its
autonomy. If disabled, the UPS will not switch back on when
mains power is restored after switching off due to the end
of its autonomy.
External options Battery Chargers N°
Sets the number of external battery chargers
KB Units
Sets the number of packs of three batteries fitted externally
➧
Sets the time and date

Set the language

Language
➧
Enables or disables the acoustic signal when buttons are
Keyboard Beep
pressed
Display
Set the backlighting of the alphanumeric display
Backlight
- Fixed: always lit
-Timed: the illumination switches off when the keypad has
been inactive for a few seconds
- Disabled: the illumination is always off
Display
Sets the contrast of the display
contrast
Password
Sets the password to access the UPS settings
Change
➧
Displays the events stored in the UPS memory, for example
Log View
END OF AUTONOMY, OVERHEATING ALARMS etc.. with
relative TIME and DATE
Log Reset
Deletes the events stored in the UPS memory
Select the setting to alter
Increases/Decreases the setting
45
