„ Use the skid plates to adjust the distance of the
clearing plate from the surface. Do not operate
the machine on gravel surfaces.
„ Never lift or carry the machine while the engine is
running.
„ Do not eat, drink or smoke while filling with petrol
or engine oil.
„ Do not inhale petrol fumes.
„ Take precautions to ensure that discharged snow
does not cause injury to persons or animals or
damage to buildings, vehicles or other objects.
Make sure that traffic is not impaired and that driv-
ers are not endangered.
„ Keep hands out of the snow discharge chute while
the machine is running.
„ Keep hands and feet away from the auger and im-
peller while the machine is running.
„ Do not clear snow from roofs.

Assembly

Caution!
Do not operate the machine until it has been
fully assembled.

Required tools

„ 2 Open-end or ring spanners, size 10
„ Open-end or ring spanner, size 13
„ Hex key, 5 mm
„ Combination or needle nose pliers
„ Screwdriver
„ Spray oil
„ Tyre pump with pressure gauge (auto tyre valve)
Assembly sequence
Attaching and adjusting control cables
The same procedure applies for the wheel
drive and auger control cables.
1. Guide the control cable upward:
Guide the auger control cable through the
„
opening on the drive speed selection plate
( 3-1).
469186_e
Guide the wheel drive control cable upward
„
under the drive speed selection plate
(
2. Loosen the screw with the hook from the adjust-
ment nut (
screw.
3. Raise the clutch lever (
4. Mount the hook into the hole on the clutch lever
from the guide handle side (
5. Screw the adjustment nut to the attached screw
until there is no slack in the cable (lightly tight-
ened) (
so that it does not twist.
6. Tighten the lock nut (
x The control cables are installed.
Attaching the drive speed selection lever
1. Guide the pre-assembled drive speed selection
lever through the drive speed selection plate
( 8-1).
2. Remove the mounting screw from the connection
bolt and attach the drive speed selection lever
9).
(
3. Secure the drive speed selection lever with the
horizontal mounting screw (
tighten the screw yet.
4. Adjust the lever position with the adjustment
screw so that it engages into the slot for the first
speed setting (1) (
5. Lock the adjustment screw (
6. Tighten the mounting screw with the self-locking
nut (
x The drive speed selection lever is at-
tached.
Attaching the snow discharge chute
1. Lightly lubricate the surface of the snow dis-
charge chute that slides against the snow blower
with spray oil (
2. Mount the discharge chute (
3. Insert mounting screws into the lower, larger
guide plate and attach the smaller guide plate (
12-1).
Autogoods "130"
3-2).
4-1). The lock nut remains on the
5).
7-1). Hold the cable while tightening
7-2).
10-1). Do not
8-2).
10-1).
11).
