EuroLite LED KLS Scan Next FX Bedienungsanleitung Seite 43

7-channel mode: Small mode in which the brightness of all spots together as well as different programs for
the derby, the scanners and the UV LEDs can be called up.
Channel
1
2
3
4
5
Derby
6
Scanner
7
UV Strobe
13-channel mode: In this mode, the spots and derby are controlled together in terms of color, and the
scanners can be controlled together in all functions.
Channel
1
2
3
4
5
Derby Motor
6
Scanner Pan
7
Scanner Tilt
8
Scanner Pan/Tilt
9
Scanner Colors
10
Scanner Gobos
Value
000‒255 Red 0-100%
000‒255 Green 0-100%
000‒255 Blue 0-100%
000‒255 White 0-100%
000–005 No function
006–055 Program 1 slow > fast
056–105 Program 2 slow > fast
106–155 Program 3 slow > fast
156–205 Program 4 slow > fast
206–255 Program 5 slow > fast
000–005 No function
006–031 Pan /Tilt program 1
032-063 Pan /Tilt program 2
064-095 Pan /Tilt program 3
096-127 Pan /Tilt program 4
128-159 Pan /Tilt program 5
160-191 Pan /Tilt program 6
192-223 Pan /Tilt program 7
224-255 Pan /Tilt program 8
000–005 No function
006–010 On
011–255 Strobe effect slow > fast
Value
000‒255 Red 0-100%
000‒255 Green 0-100%
000‒255 Blue 0-100%
000‒255 White 0-100%
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
000–255 Pan movement
000–255 Tilt movement
000–255 Pan/Tilt speed fast > slow
000–015 White
016–031 Blue
032–047 Orange
048–063 Red
064–079 Light blue
080–095 Light yellow
096–111 Light green
112–127 Magenta
128–143 White + blue
144–159 Orange + red
160–175 Light blue + light yellow
176–191 Light green + magenta
192–207 White + orange
208–223 Blue + red
224–239 Light blue + light green
240–255 Light yellow + magenta
000–015 Gobo 1
016–031 Gobo 2
032–047 Gobo 3
Function
Function
43/56
Spots
Spots and Derby
