Operating instructions
GB
8.5mm CCD colour Camera, 540 TVL,
3.7-12mm

Intended use

This 8.5mm colour camera with 42 IR-LEDs serves for image monitoring and protection
of secluded or critical areas (e.g. shop and car park surveillance, house entrances etc.)
and is only suitable for use in outside areas (IP 66). The IR range is 40 metres in the
dark (depending on the environmental conditions). Power is supplied via a 12 V/DC
power adapter. (Only available optionally).
At the bottom side of the camera, the ZOOM and FOCUS can be adjusted manually.
Furthermore, the camera features auto iris controlled by direct current, fl icker (FL),
auto gain control (AGC), auto electronic shutter (AES) and black light control (BLC).
The camera's integrated infrared LEDs allow night vision. Please note that coloured
image reproduction changes into black and white monochrome when increasing
darkness activates the IR-LEDs. The brightness is detected by the camera using a
photo sensor on the front.
Please bear in mind that it is prohibited by law to observe strangers with a camera
without their knowledge and consent.
Operating the product in any other way than described above is not permitted and may
lead to damage of the product, which can increase the risks such as short circuit, fi re
and electric shock. The product must not be modifi ed or converted. Always observe
the safety instructions included in these operating instructions. Read the operating
instructions carefully and keep them for later reference.
Contents
• Camera
• Mounting material (4 x crosshead screws, 4 x dowels and 1 x hexagon screw
driver)
• Operating instructions

Explanation of symbols

The lightening symbol indicates a health hazard, e.g. electric shock.
This symbol indicates specifi c risks associated with handling, function and
use.
The arrow symbol indicates special tips and operating information.
Safety and hazard notes
The warranty will be void in the event of non-compliance with these
safety instructions!
We do not assume any liability for material and personal damage caused
by improper use or non-compliance with the safety instructions!
An exclamation mark indicates important notes in these operating instructions
that should always be observed.
• The camera must not be modifi ed or converted, as not only will the CE
approval become void but also the warranty.
• The camera's integrated infrared LEDs enable night vision. Please note that
coloured image reproduction changes into black and white monochrome
when increasing darkness activates the IR-LEDs. The brightness is detected
by the camera using a photo sensor on the front.
• The camera should not be exposed to extreme temperatures, direct sunlight,
intense vibrations or heavy mechanical stress.
• If the camera is used with other devices e.g. a monitor and a power adapter,
the operating instructions and safety notices for the connected devices must
be followed.
• The use of the surveillance camera system does not replace the personal
supervision of children, or people who require special assistance, but only
serves as a support to this supervision.
The home technology brand for the entire house. More information at www.sygonix.com
• After rapid changes in temperature, the camera requires a certain time to
stabilise, in order to adjust to the surrounding temperature, before it can be
used.
• Electronic devices are not toys and should be kept out of the reach of
children!
• Please contact a qualifi ed person if you are unsure about the safety and
correct use of the camera.
• Never leave the packaging material lying around unattended. Plastic
foil/bags etc. can be dangerous playthings for children, there is a risk of
suffocation.
• If you have a reason to assume that safe operation is no longer possible,
disconnect the device immediately and secure it against inadvertent
operation.
• Safe operation must be presumed to be no longer possible, if
- the device is visibly damaged,
- the device does not function any longer and
- the device has been stored under unfavourable conditions for a long period
of time or
- it has been subjected to considerable stress during transportation.
• In commercial institutions, the accident prevention regulations of the
Employer's Liability Insurance Association for Electrical Systems and
Operating Materials are to be observed.
• At schools, educational centres, hobby and self-help workshops the
operation of the product is to be supervised by trained employees.
• The camera is suitable for operation in outdoor areas.
• Voltage is supplied via 12 V/DC (a suitable power supply is available as an
option).
• Ensure that all the electrical connections and connection cables between the
different devices and any extension cables conform to the regulations and
comply with these operating instructions.
• When installing / mounting the appliance, make sure that the connection
cable is neither pinched nor damaged by sharp edges.
• Disconnect the camera from the power supply, if the camera is not used for
longer periods of time.
• Disconnect the camera from the power supply before cleaning.
• For safety reasons, disconnect the camera from the power supply during
thunderstorms.
• Never replace damaged mains cables yourself. In such an event, disconnect
the appliance from the mains and take it to a specialist workshop.
• Never pour fl uids above electrical devices. You run the risk of causing a fi re
or a fatal electric shock. If liquids get into the device, immediately disconnect
it from the power supply, remove the plug from the mains and consult an
expert.
• Maintenance, adjustment and repair may only be carried out by a qualifi ed
specialist or a specialised repair shop.
• If you have any questions, which are not answered in this manual, please
contact our technical service or another specialist.

Installation

All connection cables must not be bent nor pinched. Functional faults, short-
circuits as well as a defect of the device might be the result.
Make sure that cables or wires are not damaged when drilling or bolting in
place.
Please note, you should position your camera away from direct sunlight
exposure (this can cause glare). Further, the camera must be protected from
dust and vibration.
The camera's integrated infrared LEDs enable night vision. Please note that
coloured image reproduction changes into black and white monochrome
when increasing darkness activates the IR-LEDs. The brightness is detected
by the camera using a photo sensor on the front.
There is a tool included, which is required to loosen and tighten the locking screws.
• Seek out a suitable mounting location for the camera.
Ensure that the plug and socket of the camera's connection cable are not
exposed to dampness. Plugs and sockets may only be used indoors. The
camera cable must (for installation in outdoor areas or in damp rooms) be
placed so it is led into a dry room.
