Remember to restore and put back the seals, sealants and sheathing inserted, before finishing
the work.
2.9.1 - Replacing the safety thermostat
• The thermostat bulb is located on the right of the cooking chamber,
behind the baking-pan support:
1) Open the right-hand side of the oven;
2) Remove the bulb inside the oven chamber;
3) Remove the thermostat wires and unscrew the fastener (B - pict.
8) Secured to the back of the control panel;
4) Put everything back in position. Secure the probe and the electrical
connections.
2.9.2 - Oven lamp
Proceed as follows:
1) Open the oven door (A - pict. 9).
2) Turn the plastic clamps (B - pict. 9) which lock the internal glass and open it up like a book.
3) Replace the bulb (C - pict. 9).
4) Reassemble everything in reverse order.
B
A
pict. 9
ELECTRIC VENTILATED OVENS
35
B
pict. 8
C
GB
