Adjusting the blade guard

WARNING! RISK OF INJURY!
► Always switch the appliance off and remove
the battery before carrying out any work on
the appliance.
RISK OF INJURY!
► Always use the angle grinder with the blade
guard . The blade guard should be
installed securely. Set it so that the highest
possible degree of safety is achieved, i.e.
the smallest possible part of the grinding
disc is exposed to the operator. The blade
guard is designed to protect the operator
from fragments and accidental contact with
the grinding tool.
RISK OF INJURY!
► Make sure that the blade guard
at at least the same angle as the additional
handle (see fig. B). Otherwise, you could
injure yourself on the roughing disc or cutting
disc.
♦ Turn the blade guard
(working position). Make sure that the blade
guard is positioned in such a way that the
blade guard fixture
5 bulges on the blade guard
(fold-out page).
♦ Ensure that the blade guard fixture
seated in the respective bulge
│ GB │ MT
■ 70
is fitted
to the required position
lies over one of the
(see Fig. E
is firmly
.

Fitting the additional handle

CAUTION!
► For safety reasons, this appliance may only
be used with the additional handle
Failure to do so can lead to serious injury.
The additional handle
onto the left, the right or the top, depending
on the job at hand.
Fitting/changing the roughing/
cutting disc
Always wear protective gloves when
changing cutting/rough grinding discs.
Pay attention to the dimensions of the roughing/
cutting disc. The diameter of the hole must fit the
attachment flange without any play. Do not use
a reducer or adapter.
NOTE
► Use only discs which are free of dirt.
■ Use only grinding discs whose permissible
speed rating is at least as high as that on the
type plate on the power tool.
■ RISK OF INJURY! Press the spindle locking
button only when the attachment spindle
is at a complete standstill.
♦ Press the spindle locking button
motor.
♦ Undo the clamping nut
mounting spanner
♦ Place the rough grinding or cutting disc with the
label side towards the appliance on the attach-
ment flange .
♦ Then replace the clamping nut
ment spindle with the raised side facing up.
.
can be screwed
to lock the
using the two-hole
(see fig D).
on the attach-
