11 Device information

1 Type and order code
2 Design
2.1 Heat source
2.2 Model
2.3 Controller
2.4 Thermal energy metering
2.5 Installation location
2.6 Performance levels
3 Operating limits
3.1 Heating water flow / return
3.2 Air
4 Flow / sound
4.1 Heating water flow internal pressure differential
according to 14511
Minimum heating water flow
4.2 Sound power level according to EN 12102
4.3 Sound pressure level at a distance of 10 m
4.4 Air flow
5 Dimensions, weight and filling quantities
2
5.1 Device dimensions
5.2 Weight of the transportable unit(s) incl. packaging
5.3 Device connections for heating system
5.4 Refrigerant; total filling weight
5.5 Lubricant; total filling quantity
6 Electrical connection
6.1 Supply voltage; fuse protection
6.2 Control voltage; fuse protection
6.3 Degree of protection according to EN 60 529
6.4 Starting current limiter
6.5 Rotary field monitoring
6.6 Starting current
6.7 Nominal power consumption at A7/W35 /
3
max. consumption
6.8 Nominal current at A7/W35 / cosϕ
6.9 Power consumption of compressor protection (per compressor)W
6.10 Power consumption of fan
7 Complies with the European safety regulations
www.dimplex.de
°C
°C
m³/h / Pa
m³/h / Pa
1
dB(A)
dB(A)
m³/h
H x W x L mm
kg
Inches
type / kg
type / litres
A
kW
A / ---
W
LA 6TU
Air
Universal
WPM EconPlus, wall-mounted
Integrated
Outdoors
1
up to 60 ± 2K / from 18
-20 to +35
1.1 / 9500
0.52 / 2400
56
29
2700
940 x 1350 x 600
165
G 1"A
R410A / 3.4
Polyolester (POE) / 0.7
3~/N/PE 400 V (50 Hz) / C 10 A
1~/N/PE 230 V (50 Hz) / C 13 A
IP 24
no
no
27
1.40/ 2.93
2.88 / 0.7
-
55
4
11
EN-9
