GEA T-smart 7 Betriebsanleitung Seite 85

Nennweite Werkstoff
DN 15 EPDM
FKM
HNBR
VMQ
DN 20 EPDM
FKM
HNBR
VMQ
DN 25 EPDM
FKM
HNBR
VMQ
DN 40 EPDM
FKM
HNBR
VMQ
DN 50 EPDM
FKM
HNBR
VMQ
DN 65 EPDM
FKM
HNBR
VMQ
DN 80 EPDM
FKM
HNBR
VMQ
DN 100 EPDM
FKM
HNBR
VMQ
DN 125 EPDM
FKM
HNBR
VMQ
DN 150 EPDM
FKM
HNBR
VMQ
430BAL009990DE_5
17.06.2020
Material D1
224-170.61
224-170.75
22,2
224-170.89
224-173.05
224-170.61
224-170.75
22,2
224-170.89
224-173.05
224-170.67
224-170.81
26,0
224-170.95
224-173.11
224-170.68
224-170.82
38,0
224-170.96
224-173.12
224-170.69
224-170.83
50,0
224-170.97
224-173.13
224-170.70
224-170.84
66,0
224-170.98
224-173.14
224-170.71
224-170.85
81,0
224-170.99
224-173.15
224-170.72
224-170.86
100,0
224-173.02
224-173.16
224-170.73
224-170.87
125,0
224-173.03
224-173.17
224-170.74
224-170.88
150,0
224-173.04
224-173.18
Maßblatt - Scheibenventil T-smart 7 - Dichtungen
D2
36,0
36,0
40,0
53,0
66,0
83,2
99,0
120,0
147,0
172,0
B
20,5
20,5
20,5
21,5
22,5
25,0
28,0
30,0
33,0
35,0
85
