4.6.7

Adapting the unit to the mains voltage

NOTE
Only cooling units with a rated voltage of 400 / 460 V, 3~ can be optionally connected to another mains voltage.
• Cooling units with the rated voltage 230 / 115 V, 1~ have no transformer options. No adjustment of the upstream fuse
is therefore required.
4.6.8

Equipotential-bonding connections

Fig. 16: Equipotential-bonding/fuses
Operating Manual | Attachment and Installation Cooling Units | Standard Controller (SC) – 230 V | 086100005d
1 Functional equipotential-bonding
signal reception with low interference between the unit
and the switch cabinet.
2 Protective equipotential bonding
components and touch voltage.
G00023
(M8 thread), for a
for metal
40/60
