AC CURRENT (45 Hz to 500 Hz)
Ranges: 200 µA, 2000 µA, 20 mA, 200 mA, 2 A
Accuracy: ±(1.5 % rdg + 5 dgts) on 200 µA to 200 mA ranges:
±(2.5 % rdg + 5 dgts) on 2 A range
RESISTANCE
Ranges: 200 , 2 k, 20 k, 200 k, 2 M, 20 M, 2000 M
Accuracy: ± (1.0 % rdg + 4 dgts) on 200 to 2 M
ranges: ± (3.0 % rdg + 5 dgts) on 20 M range
± {5.0 % (rdg -10 dgt) + 20 dgt} on 2000 M range
CONTINUITY
Audible indication: Less than 25 
DIODE TEST
Test current: 1.2 mA (approximate)
Accuracy: ±(1.5 % rdg + 3 dgts)
Open circuit volts: 3.0 dc typical
LOGIC TEST
Thresholds Logic 1 (Hi): 2.8 V ± 0.8 V
Thresholds Logic o (Lo): 0.8 V ± 0.5 V
Test voltage: TTL 5 VDC
OVERLOAD PROTECTION
Voltage, Resistance, Diode, Continuity, Logic:
600 VDC or 600 VAC rms
Current: 2 A / 1000 V fast blow ceramic fuse 6.3 × 32 mm
mA JACK: Input warning detects wrong switch / input jack
configuration
AUXILIARY FEATURES
DATA HOLD: Freeze the latest reading on the display.
RANGE: Execute manual range mode.
AUTO Power off: After auto power off, press (RANGE) button
to restart the meter, and the last reading of measurement
will be returned to the display.
