Start-up
Each device can only be taught-in to one Central Control Unit.
During teach-in, please make sure you maintain a distance of
at least 50 cm between the HomeMatic devices and the
Central Control Unit.
To teach-in your device to the Central Control Unit, proceed as follows:
• Open the "WebUI" user interface in your browser. Click the "Teach-
in devices" button on the right-hand side of the screen.
• To activate teach-in mode, click "Start teach-in mode" in the next
window.
• Teach-in mode remains activated for 60 seconds. An information
28
box shows how much teach-in time remains.
• Meanwhile, please activate the teach-in mode of your switch actua-
tor to teach-in as well. Therefore, press and hold the channel but-
ton (A) for at least 4 seconds. The device LED (B) will flash slowly
to indicate that teach-in mode is active.
• After a short time, the newly taught-in device will appear in the in-
box of your software interface. The button „Inbox (x new devices)"
indicates how many new devices have been taught-in successfully.
• If required, you can teach-in additional devices by repeating the
steps described above for each device.
• Now configure the newly taught-in devices in the inbox as de-
scribed in section „Configuring newly taught-in devices" .
Configuring newly taught-in devices
Once you have taught-in your switch actuator to the HomeMatic Cen-
tral Control Unit, it will be moved to the inbox. Here, you must configure
the device and its associated channels in order to make them avail-
able for operating and configuration tasks. Give the device a name
and assign the device/channels to a room. You can individually adjust
the switch on and off duration of the device as well as a delay time for
switching connected devices on and off.
Start-up
> 4 s
