1 Information about this manual
Please read this manual carefully before beginning operation with your
HomeMatic components. Keep the manual so you can refer to it at a
later date if you need to. If you hand over the device to other persons
for use, please hand over the operating manual as well.
Symbols used:
Attention! This indicates a hazard.
Note. This section contains important additional information.
Note. This section contains additional important information
about using the device in connection with the HomeMatic
Central Control Unit.
2

Hazard information

We do not assume any liability for damage to property or
personal injury caused by improper use or the failure to
observe the hazard information. In such cases any claim under
warranty is extinguished! For consequential damages, we
assume no liability!
Do not open the device. It does not contain any parts that can
be maintained by the user. There is a risk of electric shock if
the device is opened. In the event of an error, have the device
checked by an expert.
Do not use the device if there are signs of damage to the
housing, control elements or connecting sockets, for example,
or if it demonstrates a malfunction. If you have any doubts,
have the device checked by an expert.
Information about this manual
