Troubleshooting

6.1 Troubleshooting
Error
|Battery error|
Select |Maintenance
date|
(flashing)
Select |Undercur-
rent|
Select |Overcurren-
tSelect |
Select |Relay error|
|Power outage|
Select |Level error|
|max. pump operating
cycles|
Select |Max. number
of runs|
Select |Max. run
time|
|Motor error|
Select |Probe error|
|Flap error|
Pot-free contact
does not switch
All error messages listed here are forwarded to the potential-free contact if it has been connected and activated properly.
016-004_01
Cause
Battery is missing, is defective or voltage is
too low
The maintenance date has been reached
No maintenance date entered
Minimum power consumption of the
pump not reached.
Control unit-pump cable interrupted.
Pump is defective.
Maximum power consumption of the pump
exceeded, possible impeller blockage
Power contactor does not switch off
Power supply has failed
Control unit fuse faulty
Mains supply cable is interrupted
Incorrect layout or wiring of the probes
Maximum operating cycles exceeded
Pump running too frequently within a short
time
Pump is running too long per pumping oper-
ation
Cable break or motor faulty
Cable break or probe faulty
Flap cannot be closed completely, i.e. the
flap is blocked by an object
Backwater has been detected and the flap
cannot be closed completely, i.e. the flap is
blocked by an object
not activated or the miniature fuse is defec-
tive
Installation and operating instructions
Remedial measures
Check the battery connection, replace bat-
tery if necessary
Carry out maintenance
Enter maintenance date (see control unit
instructions)
Check the electrical cables, service the
pump and replace if necessary.
Carry out pump maintenance as described
in the instructions, replace the pump if nec-
essary.
Contact service technician
None, general power outage
Determine the reason for the tripped fuse
and replace the fuse if necessary
Check mains supply cable
Check the probe connection
Can be acknowledged. Inform customer
service. Fault appears after a further 1000
operating cycles
Check design and inform customer service
department if necessary
Check design and inform customer ser-
vice department if necessary
Pump post run time too long / set shorter
(parameter in the control unit)
Disconnect the system from the mains
power supply, disable the battery, check the
cable for correct connection and continuity;
test the function of the motor, replace if nec-
essary
Disable the battery; check the cable and
check for correct connection and continuity;
test function of probe, replace if necessary.
Pull out the mains plug, disconnect the bat-
tery, open the flap cover and remove the
blockage and restart the system
Close the emergency closure (hinged flap,
if present). Following the end of backwater,
eliminate the blockage as described above.
To install the flap cover, the flap motor must
be in the CLOSED position.
Have it checked by an electrically skilled
person, release potential-free contact if
applicable (art. no. 80777)
