V : lay the exhaust hose to a roof cap*.
ERTICALLY
H
ORIZONTALLY
outlet equipped with an air grille*.
*: Not included in delivery.
1. Drill three 8 mm holes (1) to fix the wall bracket (3). Tighten the wall bracket
using the supplied screws and dowels (2 / 3 a) on the wall.
1
2
3
3 a
OU CAN LAY THE EXHAUST HOSE AS FOLLOWS
: lay the exhaust hose to an exhaust
I
NSTALLATION STEPS
D
RILL HOLES
D
OWELS
W
ALL BRACKET
S (3x 4*30 mm)
CREWS
~ ~
