2. Please note the following illustration:
T
URN TO THE LEFT
L
➢ remove a previously installed carbon filter.
T
URN TO THE RIGHT
R
➢ place the carbon filter on the motor and turn the filter to the left slightly
or jerk it carefully until the filter is installed properly.
M
M
OTOR
3. Align the brackets of the filter with the holding mechanism of the motor and jerk
carefully until the filter locks.
F
ILTER BRACKETS
4. Install the grease filter(s).
WARNING! Install the carbon filters safely and properly; otherwise the
carbon filters can loosen and cause hazardous situations.
NOTICE! The suction capacity is decreased by installed carbon filters.
:
:
HOLDING MECHANISM
~ ~
51
Carbon filter (installed)
Bracket (holding mechanism on
the motor)
/
MOTOR
