• GROUNDING WIRE WORKS MUST BE CONSTRUCTED IN COMPLIANCE WITH INSTALLATION MANUAL.
• BE SURE TO USE THE CORD-CLAMPS AND THE UNIT COVER TO THE SPECIFIED POSITIONS WITH
ATTACHED TO THE PRODUCT. MOUNT THE UNIT COVER FOR CABLES OF CONNECTING SECTION
FIRMLY WITH THE SCREWS.
• DO NOT INSTALL NEAR CONCENTRATIONS OF COMBUSTIBLE GAS OF GAS VAPORS.
FAILURE TO FOLLOW THIS INSTRUCTION CAN RESULT IN FIRE OR EXPLOSION.
• IF A REFRIGERATION GAS LEAKS DURING INSTALLATION, BE SURE TO PERFORM VENTILATION.
IF THE REFRIGERANT GAS COMES INTO CONTACT WITH FIRE, A POISONOUS GAS MAY OCCUR.
WHEN INSTALLING AN AIR CONDITIONER, DO NOT ALLOW AIR OR MOISTURE TO REMAIN IN THE
REFRIGERATION CYCLE. OTHERWISE, PRESSURE IN THE REFRIGERATION CYCLE MAY BECOME
ABNORMALLY HIGH SO THAT A RUPTURE OR PERSONAL INJURY MAY BE CAUSED.
WARNING
• Never modify this unit by removing any of the safety guards of by-passing any of the safety interlock switches.
• Do not install in a place which cannot bear the weight of the unit.
Personal injury and property damage can result if the unit falls.
• Before doing the electrical work, attach an approved cable to the power supply cord.
And make sure the equipment to be earthed.
• For installation, use the tools and piping materials exclusively manufactured for R410A, and install securely in
compliance with this Installation Manual.
Pressure of the used HFC R410A refrigerant becomes higher approx. 1.6 times of that of the conventional
refrigerant. Therefore, if the exclusive piping materials are not used or incomplete installation is carried out, it
may cause a rupture or personal injury, as well water leak, electrical shock, and a fire may be caused.
• When installing or moving the air conditioner, do not mix air and so on than the specified refrigerant (R410A)
in the refrigeration cycle. If air and so on is mixed, the pressure in the refrigeration cycle may become abnor-
mally high so that personal injury may be caused by a rupture.
CAUTION
• Exposure of unit or water or other moisture before installation will result in an electrical short.
Do not store in a wet basement or expose to rain or water.
• After unpacking the unit, examine it carefully for possible damage.
• Do not install in a place that can increase the vibration of the unit. Do not install in a place that can amplify the
noise level of the unit or where noise and discharged air might disturb user's neighbors.
• To avoid personal injury, be careful when handling parts with sharp edges.
• Please read the installation manual carefully before installing the unit. It contains further important instructions
for proper installation.
• Never install a power capacitor for power factor improvement.
Required tools for installation work
1) Philips screw driver
2) Hole core drill (65 mm)
3) Spanner
4) Pipe cutter
5) Knife
6) Reamer
7) Gas leak detector
8) Tape measure
1
Owner's manual x 1
Downloaded from AC-Manual.com Manuals
Downloaded from www.Manualslib.com
9) Thermometer
10) Mega-tester
11) Electro circuit tester
12) Hexagonal wrench
13) Flare tool
14) Pipe bender
15) Level vial
16) Metal saw

Accessory and Installation Parts

2
manuals search engine
R410A (Special requirement)
17) Gauge manifold
(Charge hose : R410A special requirement)
18) Vacuum pump
(Charge hose : R410A special requirement)
19) Torque wrench
1/4 (17 mm) 16N•m (1.6 kgf•m)
3/8 (22 mm) 42N•m (4.2 kgf•m)
1/2 (26 mm) 55N•m (5.5 kgf•m)
20) Copper pipe gauge adjusting projection margin
21) Vacuum pump adapter
Outdoor unit
installation manual x 1
5
3
Specifications x 1
