3.3 Structure of the Multiline 6000
10
9
8
Fig. 4: Structure
1 Optional control pressure unit
2 Optional tank pressure unit
3 Power switch
4 Power cable connection
5 Optional silencer
7 6
5
6 Optional control output valves (max. 6 pieces)
7 Optional tank pressure connection
8 Optional compressed air connection
9 Control buttons
10 Display
9
Structure
1
2
3
4
