Transport And Storage; Table 20: Weights - Fischer Kälte-Klima CF EASY CFME020E Bedienungsanleitung

3
[ CF ] EASY condensing units are delivered with a holding charge of neutral gas.
The condensing unit should be located in such a place to prevent any dirt, dust, plastic bag,
leaves or papers from covering the condenser and its fins.
The unit must be installed without restricting the airflow.
A clogged condenser will increase the condensing temperature, thus reduce the cooling
capacity, and lead to a high-pressure switch tripping. Clean the condenser fins on a regular
basis.
3.1

3.1.1 Transport and storage

Figure 14: Transport and storage
3.1.2 Weights

Table 20: Weights

C6.1.6/0513-0515/E
Downloaded from www.Manualslib.com
Installation
WARNING
High pressure! Injury to skin and eyes possible! Be careful when
opening connections on a pressurized item.
Condensing unit handling
WARNING
Risk of collapse! Personal injuries! Move condensing unit only with
appropriate mechanical or handling equipment according to weight. Keep in
the upright position. Stack pallets on top of each other when not exceeding
300 kg. Do not stack single boxes on top of each other. Keep the packaging
dry at all times.
Standard compressors
Medium
Weight (kg)
temperature
CFME020E 76
CFME025E 79
CFME030E 79
CFME040E 91
CFME050E 108
CFME060E 112
CFME075E 118
manuals search engine
Condensing units
Low Weight
temperature (kg)
CFLE020E 79
CFLE025E 81
CFLE030E 81
CFLE040E 93
CFLE050E 106
CFLE060E 116
CFLE075E 122
Digital compressors
Medium Weight
temperature (kg)
CFDE040E 104
CFDE050E 112
CFDE060E 114
CFDE075E 122
21
