PIÈCES STANDARD - - STANDARDTEILEN - - STANDARD PARTS
Fig. 25 - - Directional Pedal and Linkage Group - - Lenkpedal- - /Gestängegruppe - -
Ref. Part No.
1
71677
2
75305
3
59672
4
86866
5
59668
6
82839
7
63292
8
71676
9
68866
10
14601
11
26395--1
12
71682
13
01683
14
83887
15
71680
16
54274
17
09832
18
32492
19
71678
20
71681
21
73411
22
01685
23
09023
24
08713
25
16213
26
65441
27
53963A
28
01704
29
78785
30
84170
31
49266
7400D MP426 (12- -05)
Home
Assemblage pédale de direction et timonerie
Description
Pedal, Propel, Lower
)
Pedal, Propel, Upper
Pin, Clevis, 0.37 D X 4.50l
Pin, Hair Cotter, 0.38 D .072
Wir
Pin, Clevis, 0.50 D X 4.50l
Tread, Non- - Skid, 02.2w 11.5l FußMatte
Spring
Cable, Push/Pull, 39.0l, 3.0
.25- - 28
Rod- - End, .25- - 28rh Fem
0.25b [Teflon]
Balljoint, .25- - 28 Fem, .25- - 28
Mal
Clamp, Cable, Stl, 0.56d X
0.38w, 1h
Arm Wldt, Cntrl, Pintle
Washer, Flat, #10 Ss
Bracket, Clip, Safety
Arm, Cntrl, Pintle
Isolator, Vib, Bshg, 1.1d 0.6l
.4b 0.78h
Washer, Flat, 0.81b 1.06d
.06, Stl
Washer, Flat, 0.38 Std
Bracket, Mtg, Propel
Bracket, Mtg, Cable, Propel
Shock Absorber, 2.3 Strk
Washer, Flat, 0.31 Ss
Screw, Hex, M8 X 1.25 X 35,
Ss, Fl
Nut, Hex, Lock, M8 X 1.25,
Nl, Ss
Bolt, Shld, .31d X 1.00,
.25- - 20
Tube, 00.38d 00.26b 00.3l Stl
Plt
Screw, Hex, .50- - 13 X 3.00, Fl Schraube, 1/2 Uncx3" 8.8c
Nut, Hex, Jam, .50- - 13, Ss
Washer, Flat, 0.25b 0.88d
.06, Neo
Bracket, Retainer, Safety
Tie, Cable, Nyl, 07.3l .19w 1.8
Max D
Find... Go To..
Bezeichnung
Pedal,Propel,Lower
Pedal Oben
Gabelkopfbolzen, 0.38d X
4.50l Pl
Splint
Gabelkopfbolzen, 0.50d X
4.50l Pl
Zentrierfeder,
Vorwärtsbewegung
Schub- - Zug- - Kabel
Stangenende .250- - 28 .25di
Kugelgelenk
Kabelschelle
Arm Propel
U- - Scheibe, Edelstahl,
5.4x09x0.8 N
Halterung Sicherheitsclip
Arm Propeller Unten
Dämpfer
U- - Scheibe, Stahl,
20.8x27x1.4 N
U- - Scheibe, Stahl,
10.3x22x1.5 C
Halterung
Bracket Propel Adjustment
StoßDämpfer
U- - Scheibe, Edelstahl,
8.6x15x1.3 N
Schraube, M 8x 35 D933
Ssa2
Sicherheitsmutter, Nylon, M 8
D985ssa2
Scr Shld
Distanzstück
Mutter
Scheibe, Neopren
Halterung
Kabelbinder, 20cm
10458 - - NA, CE
Designation
Pedal,Propel,Lower
Pedale
Axe De Chape, 0.38d X 4.50l
Pl
Goupille Fendue
Axe De Chape, 0.50d X 4.50l
Pl
Patin
Ressort De Centrage
Propulsion
Cable Push/Pull
Bielle .250- - 28 .25di
Articulation A Rotule
Attache Cable
Bras Helice
Rondelle Plate Ss, 5.4x09x0.8
N
Support Securite Agrafe
Bras Helice
Amortisseur
Rondelle Plate Acier,
20.8x27x1.4 N
Rondelle Plate Acier,
10.3x22x1.5 C
Support
Bracket Propel Adjustment
Amortisseur
Rondelle Plate Ss, 8.6x15x1.3
N
Vis Six Pans, M 8x 35 D933
Ssa2
Contre- - Ecrou Hex. Nylon, M
8 D985ssa2
Scr Shld
Entretoise
Vis Six Pans, 1/2 Uncx3" 8.8c
Ecrou
Rondelle Neoprene
Support
Serre- - Cable, 20cm
Qty/
Zahl
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
3
6
3
1
1
1
4
1
1
1
2
1
3
1
1
1
2-59
