CARE AND CLEANING

REMOVING BLOCKADE IN THE CONICAL BURR GRINDER

This step is only required if there's a blockade between the grinding burrs
and the grinder outlet.
1 2
1 2
POWER GRIND AMOUNT FILTER SIZE
POWER GRIND AMOUNT FILTER SIZE
Remove hopper Set GRIND SIZE to '1'
(finest setting)
8 9
8 9
Remove blockade at Clean coffee outlet
duct with cleaning
the grinder duct using
brush
the cleaning brush
or a pipe cleaner
168
3
3
GRIND SIZE
GRIND SIZE
LOOSEN NUT
LOOSEN NUT
Use 10mm socket.
Rotate clockwise to
remove nut
10
10
SINGLE DOUBLE
SINGLE DOUBLE
3
3
2
2
PUSH TO GRIND
PUSH TO GRIND 1
1
1. FELT WASHER
1. FELT WASHER
2. METAL WASHER
2. METAL WASHER
3. GRIND FAN
3. GRIND FAN
Reinstall grind fan &
washers using long
nose pliers
4 5
4 5
GRIND SIZE
GRIND SIZE
Set GRIND SIZE to '16' Remove top burr
(coarsest setting)
11 12
11 12
TIGHTEN NUT
TIGHTEN NUT
Insert lower burr (drive Rotate anti­clockwise
pin & cavity to align). to tighten nut
Insert flat washer &
spring washer
WARNING:
Care should be taken as the grinder burrs
are extremely sharp.
6 7
6 7
1
1
2
2
3
3
1. GRIND FAN
1. GRIND FAN
2. METAL WASHER
2. METAL WASHER
3. FELT WASHER
3. FELT WASHER
Before removing the Remove grind fan
lower burr, loosen nut & washers using long
& remove spring & flat nose pliers
washer
13 14
13 14
GRIND SIZE
GRIND SIZE
Reinsert top burr Set GRIND SIZE to '5'.
Place hopper on the
machine
