ASROCK Z490 Phantom Gaming 4/ax Schnellinstallationsanleitung Seite 6

No. Description
1 ATX 12V Power Connector (ATX12V1)
2 ATX 12V Power Connector (ATX12V2)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
5 CPU Fan Connector (CPU_FAN1)
6 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
7 RGB LED Header (RGB_LED2)
8 Addressable LED Header (ADDR_LED2)
9 Post Status Checker (PSC)
10 ATX Power Connector (ATXPWR1)
11 USB 3.2 Gen1 Header (USB3_3_4)
12 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
13 SATA3 Connector (SATA3_1)
14 SATA3 Connector (SATA3_0)
15 SATA3 Connector (SATA3_3)
16 SATA3 Connector (SATA3_2)
17 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
18 SPI TPM Header (SPI_TPM_J1)
19 Power LED and Speaker Header (SPK_PLED1)
20 SATA3 Connector (SATA3_5)
21 SATA3 Connector (SATA3_4)
22 System Panel Header (PANEL1)
23 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
24 USB 3.2 Gen1 Header (USB3_5_6)
25 USB 2.0 Header (USB_3_4)
26 Addressable LED Header (ADDR_LED1)
27 COM Port Header (COM1)
28 Front Panel Audio Header (HD_AUDIO1)
29 RGB LED Header (RGB_LED1)
30 Clear CMOS Jumper (CLRMOS1)
31 Thunderbolt AIC Connector (TB1)
32 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
