LEGEND FOR SCOPE OF DELIVERY
A Rail incl� chain
B Connection rails
C Central rails
D End rail
E Wall mount
F Garage door drive
G Drive adapter
H Bracket
I M6 hexagon nut
J "Long" collar stud with cotter pin
K Rail holder
L Ceiling mounting bracket
Fastening material for the door and wall is not included in the scope of delivery�
TECHNICAL DATA
Smart DRIVE L / Smart DRIVE XL
Item no.
Operating voltage
Rated output
Standby consumption
Maximum force
Speed
Lighting
Burn time
Radio frequency
Signal strength
Ambient temperature
Max. door size
Protection class
Protection class
Handheld transmitter
Item no.
Model/type
Radio frequency
Signal strength
Power supply
Battery type
Protection class
Ambient temperature
M M6 hexagon screw
N Door mounting piece
O Door arm (coupling rod)
P "Short" collar stud with cotter pin
Q Manual door release cable
R Upper end stop (limit block)
S Drilling screws
T Handheld transmitter
U Power cord
V Wall mount (Handheld transmitter)
W Interior switch
X Light barrier
60923 / 60924
220 V–240 V AC 50/60 Hz
200 W / 245 W
5 W / 7 W
600 N / 1000 N
0.15 m/s
LED 12 V DC
3 min.
868.4 MHz
max. 10 mW
-20°C to +40°C
10 m² / 14 m²
IP 20. Only for dry indoor rooms.
60930 / 60931
Wireless handheld transmitter, 868 2-channel/4-channel
868,4 MHz
max. 10 dBm / 10 mW
3 V DC
CR2032 (lithium battery)
IP 20. Only for dry indoor rooms.
-10°C to +55°C
