Elektrische Teile; Spezifikation - Promac SX-835DGSVI Anleitung

Symbol BESCHREIBUNG
M1 Blade Motor
M2 Hydraulic Motor
M3 Coolant Pump
KM1 Contactor (Blade)
KM2 Contactor (Hydraulic)
KM3 Contactor (Coolant Pump)
KM2 Auxiliary Contact 2A
FS2 Thermal Relay (Hydraulic)
FS3 Thermal Relay (Coolant Pump)
U2 Inverter
T1 Transformer
SA1 Power Switch
K2 Relay
K3 Relay
K1 Relay
K4 Relay
K5 Relay
FU1 Fuse
FU2 Fuse
FU3 Fuse
FU4 Fuse
FU5 Fuse
FU6 Fuse
KT1 Timer
KT2 Timer
KT3 Timer
SQ7 Upper Limit
SQ5 Down Limit
SQ3 Blade Broken Sensor
SQ1 Saw Frame Cover Limit Switch
VR Speed Adjustment VR
SB1 Emergency Switch (1B)
SA3 Raise / Down Ternary Form Switch
SA4 Clamp / Release Ternary Form Switch
SA2 Manual / Auto Switch
SB2 Hydraulic Start Button
HL2 Hydraulic Start Indicator
SB4 Auto Cutting Button
HL3 Auto Cutting Indicator
HL1 Power Indicator
SB3 Blade Stop Button
SB5 Blade Start with Manual Button
YV1 Saw Frame Down Valve
YV2 Vise Clamp Valve
SX-835DGSVI

Elektrische Teile

TYPEN-Nr. (Marke)
C12D (NHD)
C09D (NHD)
C09D (NHD)
CA1-D20
NTH-1.45A (NHD)
RHU-0.16A (TECO)
RM6 (Rhymebus)
160VA (SUN CHUAN)
NDS-40D (NHD)
LB4HN-24AC (RELAY)
LB4HN-24AC (RELAY)
LB2HN-24AC (RELAY)
LB2HN-24AC (RELAY)
LB2HN-24AC (RELAY)
12A (QIAODIAN)
12A (QIAODIAN)
12A (QIAODIAN)
1A (QIAODIAN)
1A (QIAODIAN)
5A (CONQUER)
H3-M1 (FOTEK)
H3-M1 (FOTEK)
H3-M1 (FOTEK)
TZ-8104(TWCHT)
TZ-8111(TWCHT)
TZ-8111(TWCHT)
AZD-S11 (SHINOZAKI)
RV24YNB102 (TOCOS)
R2PNR4 (RENY)
NSS22-S0 (NHD)
NSS22-S0 (NHD)
NSS22-S2 (NHD)
NJB22-F10 (NHD)
PL-BA9 (NHD)
NJB22-F10 (NHD)
PL-BA9 (NHD)
NLD22-WA (NHD)
NPB22-F01 (NHD)
NPB22-F10 (NHD)
DSG-3C4-N-02 (YUSAN)
DSG-202-N-02 (YUSAN)
47

SPEZIFIKATION

2.2kW/400V/3PH
0.75kW/400V/3PH
50W/400V/3PH
AC1:25A/600V CE
AC1:20A/600V CE
AC1:20A/600V CE
Ui:600Vac ith:10A CE
Ui:600Vac ith:6A CE
Ui:690Vac ith:6A CE
2.2kW/400V/3PH
1PH 160VA CE
Ui:690Vac ith:40A CE
24Vac 5A CE
24Vac 5A CE
24Vac 10A CE
24Vac 10A CE
24Vac 10A CE
12A CE
12A CE
12A CE
1A CE
1A CE
5A CE
24Vac CE
24Vac CE
24Vac CE
AC15 380V 10A IP65 CE
AC15 380V 10A IP65 CE
AC15 380V 10A IP65 CE
AC15 400V 2A IP65 CE
ROHS
Ui:600Vac ith:10A CE
Ui:600Vac ith:5A CE
Ui:600Vac ith:5A CE
Ui:600Vac ith:5A CE
Ui:600Vac ith:5A CE
24Vac 1W/440V
Ui:600Vac ith:5A CE
24Vac 1W/440V
AC24V CE
Ui:600Vac ith:5A CE
Ui:600Vac ith:5A CE
AC24V
AC24V
