Product features

Compact bar with mushrooms, spots, UV strobe, laser (RG, 2M), QuickDMX port and bag
DMX light effect bar with laser, 2 rotating LED mushrooms, 4 LED spots and UV strobe LEDs
•
2 laser diodes project hundreds of red and green laser beams
•
2 rotating mushrooms with four bright LEDs (red, green, blue and warm white) each
•
4 spots with four high-power RGB/WW LEDs (4in1) each
•
UV strobe LEDs
•
Laser class 2M: does not require additional protective measures or appointment of a laser safety
•
officer
Ultra-light ideally suited for mobile use
•
Crossbar with integrated DMX control unit and TV spigot for tripod installation
•
Swivel mounting brackets for truss mounting
•
Comes pre-assembled with practical transport bag
•
Convenient control via included IR remote control or optional wireless foot switch
•
Sound-control via built-in microphone with sensitivity control
•
6, 8, 11, 21, 25, or 29 DMX channels selectable
•
LED mushrooms and LED spots individually tiltable and controllable
•
Spots with 7° beam angle
•
Auto, music, master/slave and DMX mode
•
Brand-new software design with smart programs
•
26 built-in auto and music show programs that include all 4 effect units
•
Addressing and setting via control panel with 4-digit LED display
•
Brightness manually adjustable via rotary control
•
Supports QuickDMX - the wireless DMX system by Eurolite
•
Built-in phantom-powered USB port for QuickDMX receivers (accessories)
•
When fog is used, this effect becomes especially attractive
•
P-Con terminals for power linking up to 8 units
•
Switch-mode power supply for operation between 100 and 240 volts
•

SAFETY INSTRUCTIONS

WARNING!
Please read the safety warnings carefully and only use the product as describe in this manual to
avoid accidental injury or damage.
Intended use
• This device is a show laser for creating decorative lighting effects. This device is designed for professional
use in the field of event technology, e.g. on stage. It is not suitable for household lighting.
• Only use the device according to the instructions given herein. Damages due to failure to follow these
operating instructions will void the warranty! We do not assume any liability for any resulting damage.
• We do not assume any liability for material and personal damage caused by improper use or non-
compliance with the safety instructions. In such cases, the warranty/guarantee will be null and void.
• Unauthorized rebuilds or modifications of the device are not permitted for reasons of safety and render the
warranty invalid.
Danger due to electricity
• The device is suitable for indoor use only. Do not use it outdoors. Never expose it to rain or moisture. Do
not store it in rooms exposed to moisture.
• To reduce the risk of electric shock, do not open any part of the device. There are no serviceable parts
inside the device.
• Only connect the device to a properly installed mains outlet. The outlet must be protected by residual
current breaker (RCD). The voltage and frequency must exactly be the same as stated on the device. If the
mains cable is equipped with an earthing contact, then it must be connected to an outlet with a protective
ground. Never defeat the protective ground of a mains cable. Failure to do so could result in damage to the
device and possibly injure the user.
• The mains outlet must be easily accessible so that you can unplug the device quickly if need be.
27/48
00129744, Version 1.0
