INSTALLATION
Fastening
1. Open the appliance door.
2. Slide the oven in the kitchen cabinet.
3. Place the four spacers (A) in the holes in the frame and then tighten the four screws (B) that
are included with the appliance.
Electrical installation
This appliance is supplied with a plug and mains lead.
Cable
Cable types applicable for installation or replacement:
H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F, H05 V2V2-F (T90), H05 BB-F
To select the proper cable refer to the total power on the type plate and the table:
Total power (W)
max. 1380 W
max. 2300 W
max. 3680 W
The earth wire (green/yellow) must be 2 cm longer than the phase and neutral wires (blue and
brown wires).
A
B
Cable conductors and size (mm²)
3 x 0.75
3 x 1
3 x 1.5
EN 25
