probst RG-SAFELOCK Betriebsanleitung Seite 34

Safety
OPERATING INFORMATIONS
Symbol Meaning
Permitted or not permitted position of the suspension eye in the
baffle when gripping on slopes. Left view.
Permitted or not permitted position of the suspension eye in the
baffle when gripping on slopes. Right view.
Gripping process displayed correctly and incorrectly. Left view.
Gripping process displayed correctly and incorrectly. Right view.
Step sequence Gripping (A, B) and depositing (C, D). Left view.
See also chapter "Operation".
Step sequence Gripping (A, B) and depositing (C, D). Right View.
See also chapter "Operation".
5450.0006 V1
6 / 22
Order-No. Size
2904.0790 130 x 65
2904.0791 130 x 65
2904.0792 50 x 150
2904.0793 50 x 150
2904.0794 90 x 120
2904.0795 90 x 120
