8.6. modulation input: MOD IN

An analogous modulation signal of 0 to +5V can be driven into this socket to realize a
remote-controlled operation. The adjusted value on the potentiometer becomes no
effective. The operation mode switch must be in position "MODULATION".

8.7. power supply input socket

The device is supplied with power over this connector (9V DC/250mA). The inner pole
is "+". Use only the provided wall power supply.

8.8. actuator connection: PIEZO OUT

Please plug in the actuator here. The output voltage is in the range of 0...+150V.

8.9. malfunction handling

In case of malfunction of the equipment please check all connectors and cords for
damage. Large strains on the cords can lead to interruptions. In this case, please
contact our technical service or your distributor.
