DBX Next

6. Initial operation

Fill the mains and the appliance with water and emerge air according to
image manual.
After every draining (e.g. after work on the plumbing system or following
repairs to the appliance), the heater must be re-vented in this way before
EN
starting it up again.
If the water heater cannot be put into operation, the temperature cut-out or the pressure cut-out
may have tripped during transport. If necessary, check that the power supply is switched off and
reset the cut-out (fig. F1 + F2).
1. Switch on the power supply to the appliance.
2. Open the hot water tap. Check the function of the appliance. The heating element will be
activated after approx. 10 – 30 sec of continuous water flow.
3. Explain the user how the instantaneous water heater works and hand over the operating
instructions.
4. Fill in the guarantee registration card and send it to the CLAGE Central Customer Service or
use the online registration (see page 7).

7. Maintenance work

Maintenance work must only be conducted by an authorised professional.
Cleaning and replacing the filter strainer
The cold water connection of this instantaneous water heater is equipped with an integrated
shut-off valve and a strainer. Soiling of the strainer may reduce the warm water output. Clean or
replace the strainer as follows:
1. De-energize the instantaneous water heater (e.g. via deactivating the fuses) and prevent
inadvertent reactivation of them.
2. To open the appliance, take off the small face plate, loose the screw behind this cover and
detach the hood.
3. Close the shut-off valve (a) in the cold water connection piece (position "0" fig. G1).
4. Unscrew the screw plug (b) from the cold water connection piece and take out the strainer
(c) (fig. G2).
Note: Residual water can leak
5. The strainer can now be cleaned or re placed.
6. After fitting of the clean strainer tighten the screw plug.
7. Slowly reopen the shut-off valve in the cold water connection piece (position "1"). Check all
connections for leaks.
8. Vent the appliance by carefully opening and closing the affiliated warm water tap valve sev-
eral times until air no longer emerges from the pipe.
9. Fit the hood of the appliance. Then switch on the power again (e.g. via activating the fuses).
Modification of factory preset outlet temperature
The factory set hot water outlet temperature is 50 °C.
By turning the adjustment potentiometer with the auxiliary tool "S", this presetting can be
changed between two stops in the range of approx. 30 °C to 60 °C (see fig. F3).
The hot water outlet temperature will be increased by clockwise rotation and decreased by
counterclockwise rotation.
Note: The hot water temperature may not exceed 55 °C if the instant water heater is connected
to a shower.
Cleaning and replacing the filter strainer if direct connected
The cold water connection of this instantaneous water heater is equipped with a strainer. Soiling
of the strainer may reduce the warm water output. Clean or replace the strainer as follows:
1. De-energize the instantaneous water heater (e.g. via deactivating the fuses) and prevent
inadvertent reactivation of them.
2. Close the shut-off valve in the mains water supply of the instantaneous water heater.
3. To open the appliance, take off the small face plate, loose the screw behind this cover and
detach the hood.
4. Unscrew mains water inlet from connection piece and take out the strainer.
Note: Residual water can leak
5. The strainer can now be cleaned or replaced.
6. After refitting the clean strainer reconnect the mains water inlet to the connection piece.
7. Slowly reopen the shut-off valve in the mains water supply. Check all connections for leaks.
8. Vent the appliance by carefully opening and closing the affiliated warm water tap valve sev-
eral times until air no longer emerges from the pipe.
9. Fit the hood of the appliance. Then switch on the power again (e.g. via activating the fuses).
11
(fig. G3).
