7. Fault finding the product

WARNING
Electric shock
Death or serious personal injury
Before starting any work on the product, make sure
that the power supply has been switched off and that
it cannot be accidentally switched on.
Fault
1. The pump does not start
when started.
2. The pump is constantly off.
3. The MP 204 gives a faulty
control signal.

8. Technical data

Material Steel plate
Mains supply 3x400 V, 50 Hz, N, PE
DOL: Direct On Line
Starting method
SD: Star-Delta
DOL: 3-290 A
Rated current
SD: 3-290 A
Operating temperature 0 to +35 °C
Storage temperature +10 to +60 °C
Humidity 80 % at +25 °C
Enclosure class IP54
Temper Cold. The product must be
installed in a well-ventilated room
Climatic condition away from direct sunlight,
precipitation, wind, sand, salt and
dust from the atmosphere.

9. Disposal of the product

This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company
or service workshop.
Possible cause
a) No power supply.
b) Damaged switchgear or contactor.
c) Cut-in value not reached, level or pressure.
d) Relay defective.
e) Wiring defective.
f) Pump defective.
g) An alarm occurs
a) Cut-in value not reached, level or pressure.
b) Control relay defective.
c) Contactor defective.
a) The MP 204 is defective.
b) Incorrect setup of the MP 204.
Remedy
Check that the power cables are connected
correctly.
Replace switchgear or contactor.
Check the cut-in values.
Replace the relay.
Replace the cable.
Repair or replace the pump, if necessary.
Check the type of fault in the alarm log for MP
204.
See installation and operating instructions for
the MP 204.
Check the cut-in values.
Replace the control relay.
Replace the contactor.
See installation and operating instructions for
the MP 204.
