Consumer Amperage Provisional
uninterrupted
operation
Halogen lamp
(HL 12-55,
4.5 A 4 h
Art. No. 10.955.00)
Car vacuum
cleaner 7 A 2.5 h
TV with satellite
receiver 4 A 4.5 h
Cool-box 4 A 4.5 h
12V immersion
pump 4.5 A 4 h
Check that the voltage and current ratings of the
consumer units will not overload the energy
station.
Overloading may destroy the energy station.
7. To operate the lamp
Proceed as follows to switch on the lamp:
¼
The lamp (Figure 1 / Item 6) is switched on and
off using the switch (Figure 1 / Item 7).
8. Starting aid for motor vehicles
¼
The charging cable with the pole clamps is
located on the side of the unit.
¼
When the jumper cables are not in use, do not
remove them from the energy station.
¼
Caution! Risk of short-circuiting if the pole clamps
touch each other.
¼
Use the energy station as a source of starting aid
only when the vehicle battery is partially
discharged. The energy station is designed
provide the car battery with only a limited charge.
¼
The energy station is not suitable for starting
a vehicle with a fully discharged battery.
The energy station's starting aid function provides
welcome help when a vehicle's battery lacks
sufficient charge to start the vehicle without difficulty.
We wish to point out that even standard vehicle
models are equipped with numerous electric modules
17.04.2003 9:59 Uhr Seite 11
(e.g. ABS, ASC, fuel injection pump, on-board
computer and car phone). The higher starting voltage
and voltage peaks may cause damage to electronic
components. No product liability can be accepted for
any damage resulting from the energy station's
starting aid function. Please read the information in
the operating manuals of your vehicle, radio, car
phone, etc. Important! The energy station has to be
charged to full capacity in order to be able to draw a
current of 600 A for 5 seconds.
How to use the energy station to start a vehicle
1. Connect the red cable (+) of the energy station to
the POSITIVE pole (+) of the vehicle battery.
2. Connect the black cable (-) of the energy station
to the vehicle's earthing strip or any other bare
point on the engine block (earth). Choose a point
as far away as possible from the battery in order
to prevent ignition of any explosive electrolytic
gas which may develop.
3. The switch (Figure 1 / Item 1) must be set to
„ON" position.
4. Turn the ignition key over to start position and
wait approx. 2 minutes.
DO NOT START THE ENGINE!
5. With the energy station connected, you can now
try to start the engine. Do not attempt to start the
vehicle for longer than 5 seconds because of the
very high current involved.
6. First disconnect the pole clamp from the vehicle's
earthing strip (negative pole).
7. Then disconnect the jumper cable from the
POSITIVE pole (+) of the vehicle battery.
8. The energy station will need to be recharged
after giving this starting aid.
9. Battery status monitoring
The voltage meter (Fig. 1/Item 5) keeps you
constantly informed as to the charge status of the
battery.
The red LED (Figure 1 / Item 4) lights up as soon as
you start to charge the energy station.
¼
Green
The battery is 50 - 100 % full.
¼
Yellow
The battery is 0 - 50 % full and should be
recharged.
¼
Red
The battery is completely run down. The battery
can reach this state after jump starting a vehicle,
for example. The battery must be recharged.
Continuing to operate the unit from this point
